Self-propelled asphalt distributor
Detail Information
Self-propelled asphalt distributor
Drive system
Full hydraulic driving and pumping system
Spraybar
2m spray bar with auto pneumatic valve control
Generator
Yamaha Generator supply the power to Burner
Heating
Italy Riello automatic ignition burner G10
Model: ZMSP-10
Dimension(mm)： 4000×1800×1800
Drawbar Length(mm)： 1000
Drive Model： Self-Propelled Hydraulic Drive
Walking Speed(m/min): 50-80
Axis: 1
Brake model: Oil brake
Tire specification: 28×9-15 NHS
Tank capacity(L): 1200
Insulation Thickness: 50mm Fiber glass
Spray valve: 0.5-3.0kg
Spray bar length(m): 1.8
Spray bar nozzles: fan-shaped, 14pcs
Hang Spray Rod: Length (m) 5
Hand spray nozzle: Slottype , 2 pc
Engine model: Changchai N490B 39kw
Cooling method： water cooling
Generator model： YAMAHA
Generator power： 1.5KW
Burner： G10
Ignition types： Auto
Asphalt pump model: CLB-100
Asphalt pump flow(m³/h): 6m³/h
Max. air pressure (Mpa): 0.8
Asphalt cleaning: Pressure air blow + Diesel oil
